1. Overview
The 400 meter water well drilling rig is an advanced and practical drilling equipment that plays a crucial role in ensuring people's domestic water supply, agricultural irrigation, and industrial production. We should fully leverage its advantages, better utilize groundwater resources, promote the development of water conservancy projects, and bring more convenience and well-being to people's lives.
| Maintenance level | Time/Mileage | Core content | Estimated working hours |
| Routine maintenance | Every 8 hours | Oil level/filter element/bolt inspection | 0.5-1 hour |
| Elementary maintenance | 250 hours | Lubrication point oil injection+instrument calibration | 2-3 hours |
| Secondary maintenance | 1000 hours | Hydraulic oil replacement+gearbox disassembly and inspection | 8-12 hours |
| Overhaul and maintenance | 8000 hours | Engine maintenance+structural component inspection | 72 hours+ |
Power motor: Dual power motor design, high torque
Dual use of water and gas: can be modified for dual use of water and gas, with fast drilling speed
Integrated control: simple operation, easy to get started
Save space and provide powerful lifting power for deep holes
Dual hydraulic motor power head: Depth up to 400 meters, high efficiency
Regional demand ratio distribution
I. North American market (accounting for approximately 35% -40%)
II.
1. Dominant position: North America is the world's largest demand market for drilling rigs, and the shale gas revolution in the United States has driven sustained demand for efficient drilling rigs such as horizontal drilling rigs and fracturing equipment. Canada has seen significant growth in demand for oil sands resource development and polar drilling.
2. Technology driven: The demand for intelligent drilling rigs (such as Atlas Copco's automated drilling system) and environmentally friendly equipment (low emission drilling rigs) accounts for over 50%.
III.European market (accounting for approximately 20% -25%)
IV.
1. Green energy transformation: Geothermal and offshore wind power projects in Germany, the UK, and other countries have driven the demand for modular drilling rigs, and environmental regulations have prompted companies to purchase low-noise and low vibration drilling rigs.
2. Deep well drilling: Nordic countries (such as Norway) widely use high-pressure drilling rigs in deep-sea oil and gas exploration, accounting for over 30%.
V.Asia Pacific market (accounting for approximately 25% -30%)
VI.
1. Growth in emerging markets: China and India have strong demand for infrastructure construction and mineral development, with drilling rig imports from Southeast Asian countries such as Indonesia and Vietnam growing at an average annual rate of 12%.
2. Energy exploration: Australia has stable demand for coal and iron ore drilling, while Japan and South Korea are focusing on upgrading geothermal drilling technology.
VII.Middle East and Africa (accounting for approximately 10% -15%)
VIII.
1. Traditional oil and gas dominance: Saudi Arabia and the United Arab Emirates account for 70% of the region's total demand for oil drilling rigs, while African countries (such as Nigeria) are driving the purchase of small drilling rigs due to shallow oil and gas development.
2. Mining potential: The exploration of precious metals and copper mines in South Africa and the Democratic Republic of Congo has driven an increase in demand for fully hydraulic drilling rigs.
SL400S WTAER DRILL RIG DETAILS
| Technical parameters | SL400S | SL500S | SL650S |
| Max drilling depth(M) | 400 | 500 | 650 |
| Drilling diameter(mm) | 105-325 | 105-400 | 105-450 |
| Air pressure(Mpa) | 1.2-3.5 | 1.2-3.5 | 1.6-6 |
| Air consumption(mm³/min) | 16-55 | 16-55 | 16-75 |
| Drill pipe length(m) | 7 | 7 | 6 |
| Drill pipe diameter(mm) | 89/102 | 102 | 89/102 |
| Axial pressure(T) | 4 | 6 | 6 |
| Lifting force(T) | 22 | 30 | 38 |
| Fast lifting speed(m/min) | 29 | 29 | 28 |
| Fast feeding speed(m/min) | 56 | 48 | 60 |
| Max rotary torque(Nm) | 8000/4000 | 11000/5500 | 13000/6500 |
| 15000/7500 |
| Max rotary speed(r/min) | 75/150 | 75/150 | 95/190 |
| Big secondary winch lifting force(T) | - | - | Can be added 5 tons |
| Small secondary winch lifting force(T) | 1.5 | 1.5 | 2.5 |
| Jacks stroke(m) | 1.6 | 1.6 | 1.6 |
| Drilling efficiency(m/h) | 10-35 | 10-35 | 10-35 |
| Moving speed(km/h) | 2.5 | 3 | 3 |
| Uphill angle(Slope) | 21° | 21 | 21° |
| Weight of the rig(T) | 9.8 | 10.6 | 13 |
| Dimension(M) | 6.26*1.85*2.43 | 6.52*1.85*2.51 | 6.73*2.1*2.75 |
WHO ARE WE?
FAQ:
1. Are you a trading company or a manufacturer?
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.
2. How can we guarantee quality?
Always a pre-production sample before mass production;always final inspection is done before shipment;and our main unit has a one-year warranty, during which all damaged accessories can be replaced with new ones. We provide machine installation and operation videos.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.
4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.
5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.
6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
7.Can you do OEM for me?
We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
